MOC wide-angle image M03-01114

context image for 1113


MOC wide-angle image M03-01114
MOC wide-angle image M03-01114
View full-size image, processed, in sinusoidal projection using 326.60°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 326.60°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-01114

Acquisition parameters
     Image ID (picno): M03-01114
     Image start time: 1999-07-06T14:07:29.89 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-NONE
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    326.60°W
Latitude  of image center:     24.75°S
       Scaled pixel width:    236.14   meters
      Scaled image  width:    114.46   km
      Scaled image height:    119.08   km
     Solar longitude (Ls):    166.05°
    Local True Solar Time:     14.75   decimal hours
           Emission angle:      3.43°
          Incidence angle:     50.64°
              Phase angle:     47.75°
            North azimuth:     93.51°
              Sun azimuth:     35.12°
      Spacecraft altitude:    374.77   km
           Slant distance:    375.37   km

Policy regarding use of processed images

Release date: 22 May 2000
