MOC wide-angle image M03-00900

context image for 899


MOC wide-angle image M03-00900
MOC wide-angle image M03-00900
View full-size image, processed, in sinusoidal projection using 314.53°W as prime meridian
(lossy JPEG, medium quality, rapid download)
View full-size image, processed, in sinusoidal projection using 314.53°W as prime meridian
(lossless GIF, best quality, slow download)
View full-size image, processed but NOT map-projected
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format
Hint: configure your browser to recognize files with extensions .IMG and .IMQ as MIME type application/octet-stream and to save them to disk.

Ancillary data for MOC wide-angle image M03-00900

Acquisition parameters
     Image ID (picno): M03-00900
     Image start time: 1999-07-05T12:38:14.90 SCET
         Image  width:    480      pixels
         Image height:    480      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.05
   Crosstrack summing:      1
    Downtrack summing:      1
     Compression type: MOC-PRED-X-5
            Gain mode:     4A (hexadecimal)
          Offset mode:      7 (decimal)
Derived values
Longitude of image center:    314.53°W
Latitude  of image center:     24.45°S
       Scaled pixel width:    235.78   meters
      Scaled image  width:    114.28   km
      Scaled image height:    119.09   km
     Solar longitude (Ls):    165.48°
    Local True Solar Time:     14.75   decimal hours
           Emission angle:      3.42°
          Incidence angle:     50.59°
              Phase angle:     47.71°
            North azimuth:     93.48°
              Sun azimuth:     35.15°
      Spacecraft altitude:    374.18   km
           Slant distance:    374.79   km

Policy regarding use of processed images

Release date: 22 May 2000
