MOC wide-angle image S03-00614

Noachis Terra in late winter


MOC wide-angle image S03-00614
MOC wide-angle image S03-00614
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image S03-00614

Acquisition parameters
     Image ID (picno): S03-00614
     Image start time: 2005-02-11T11:05:45.60 SCET
         Image  width:    512      pixels
         Image height:   1920      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.00
   Crosstrack summing:      4
    Downtrack summing:      4
     Compression type: MOC-NONE
            Gain mode:     3A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:      0.12°W
 Latitude of image center:     58.27°S
       Scaled pixel width:    980.92   meters
      Scaled image  width:    640.19   km
      Scaled image height:   1888.12   km
     Solar longitude (Ls):    158.56°
    Local True Solar Time:     15.08   decimal hours
           Emission angle:     17.92°
          Incidence angle:     77.43°
              Phase angle:     64.52°
            North azimuth:     95.59°
              Sun azimuth:     47.19°
      Spacecraft altitude:    376.03   km
           Slant distance:    393.17   km

Policy regarding use of processed images

Release date: 12 October 2005
