MOC wide-angle image S03-00606

Mountains of Mitchel near the southern terminator in late winter


MOC wide-angle image S03-00606
MOC wide-angle image S03-00606
View full-size image, processed but NOT map-projected
(lossy JPEG, medium quality, rapid download)
View full-size image, processed but NOT map-projected
(lossless GIF, best quality, slow download)
Download processed image in PDS .IMG format
Download compressed raw data in PDS .IMQ format

Ancillary data for MOC wide-angle image S03-00606

Acquisition parameters
     Image ID (picno): S03-00606
     Image start time: 2005-02-11T09:07:54.85 SCET
         Image  width:    512      pixels
         Image height:   1440      pixels
Line integration time:     80.4800 millisec
   Pixel aspect ratio:      1.00
   Crosstrack summing:      4
    Downtrack summing:      4
     Compression type: MOC-NONE
            Gain mode:     3A (hexadecimal)
          Offset mode:      5 (decimal)
Derived values
Longitude of image center:    330.39°W
 Latitude of image center:     62.36°S
       Scaled pixel width:    978.60   meters
      Scaled image  width:    638.15   km
      Scaled image height:   1415.27   km
     Solar longitude (Ls):    158.52°
    Local True Solar Time:     15.15   decimal hours
           Emission angle:     17.87°
          Incidence angle:     80.43°
              Phase angle:     67.83°
            North azimuth:     96.28°
              Sun azimuth:     47.80°
      Spacecraft altitude:    375.01   km
           Slant distance:    392.00   km

Policy regarding use of processed images

Release date: 12 October 2005
